DC MCB BREAKER 1POLE 10A 250V 6KA MINIATURE ELECTRICAL CIRCUIT MINI MCB BREAKERS - 副本

DC MCB BREAKER 1POLE 10A 250V 6KA MINIATURE ELECTRICAL CIRCUIT MINI MCB BREAKERS - 副本

Short Description:

DC MCB supplementary protectors are designed to provide over-current protection within appliances or electrical equipment, where a branch circuit protection is already provided or not required. Devices are designed for direct current (DC) control circuit applications....


Product Details

Product Tags

Product Name
Dc Mcb Breaker 1pole 10a 500v 6ka Miniature Electrical Circuit Mini Mcb Breakers
Rated voltage
500V
Rated current
10A
Breaking capacity
6kA
Poles
1P
Working Temperature
-35°C-70°C
Certificate
TUV 、CE、ROHS、
Features
1. Overload and the short circuit protection function
2. Non-polarity and Polarity both available
3. Rated short circuit breakingcapacity up to 6kA
4. Rated Voltage up to 500V
5. Rated Current In up to 10A
6. Designed for PV, energy storage and other DC applications
7. 2 years warranty, product insurance, and recall insurance available


FAQ

Q: Are AC and DC circuit breakers the same?
A: For instance, the AC voltage and current may have different effect in the circuit other than the DC with the same level of voltage. For this reason, An AC circuit breaker can't be used for DC circuits. Similarly, DC circuit breakers can not be used for AC circuits.

Q: What is DC circuit breaker?
A: DC circuit breakers can be used to protect individual loads that work with direct current, or they can be used to protect main circuits such as those of inverters, solar PV arrays, or battery banks.

Q: Are DC breakers different than AC breakers?
A: In short, DC is difficult to extinguish the arc, while AC is easy to extinguish the arc with an overshoot of zero.

Q: When I can receive quotation and detail information after send the enquiry?
A: Reply will be sent in 48hours.

Q: Could I know the payment method please?
A: 1) Standard order could pay by T/T,L/C
2) Small order could support the Paypal, Western Union, Money Gram(credit card acceptable).

Q: What's your main product?
A: We have two product projects, low voltage DC and AC electrical

Q: Do you have warranty policy?
A: We offer at least 2 year-warranty for our products, longer warranty for products, and full lifespan aftersales service.
